CS solid ceramicized silicone rubber

CS solid ceramicized silicone rubber

CS-70 solid ceramifiable silicone rubber stays workable at ambient temperature, then forms a rigid ceramic body above 600°C (1112°F) — no cracking after 30 minutes at 1200°C (2192°F) and no burn-through under sustained 1000°C flame.

CS-70-series ceramifiable solid silicone behaves like any premium silicone at room temperature, then converts above 600°C (1112°F) into a hard ceramic body that insulates, blocks flame, and cushions. It shows no cracking after 30 minutes at 1200°C (2192°F) and withstands sustained 1000°C (1832°F) flame without burn-through. UL 94 V-0 certified (Yellow Card File No. E499089) with compliant smoke toxicity, it can be laminated with glass-fiber cloth for integrated production — the fire-protection material of choice for rolling stock, industrial equipment, and electronics.

Product Advantages

  • UL94V-0 fire retardant
    UL94V-0 fire retardant
  • Can't be burned or crack
    Can't be burned or crack
  • Can withstand 1000°C flame temperature for a long time without burning through
    Can withstand 1000°C flame temperature for a long time without burning through
  • Can be form into a ceramic support when>600°C
    Can be form into a ceramic support when>600°C
  • Good aging and chemical stability
    Good aging and chemical stability
  • The flue gas after combustion meets the requirements for smoke, fire and poison
    The flue gas after combustion meets the requirements for smoke, fire and poison

Performance Parameters

Properties

Test Method

Typical Value

Product

/

CS-70

CS-70-G

CS-70-H-G

CS-70-M

Color

Visual

Gray, Black

Gray, Black

Gray, Black

Gray, Black

Thickness (mm)

Tolerance (%)

ASTM D374/D374M

/

0.2~5.0

±10

0.3~5.0

±10

0.2~5.0

±10

0.2~0.5

±15

Density (g/cm3)

ASTM D792

1.4

>1.4

>1.4

1.6

Hardness (Shore A)

ASTM D2240

70±5

>70

>65

>65

Compression Set (%)

(25%, 150℃, 168h)

ASTM D395

<12

<12

<15

/

Tensile Strength (MPa)

ASTM D412

2

25

2.7

20

Elongation at Break (%)

ASTM D412

70

/

/

/

Tear Strength (N/mm)

ASTM D624

7

50

13

25

Thermal Conductivity (W/(m·K))

ASTM E1461

0.3

0.3

0.3

0.3

Dielectric Strength (kV/mm)

ASTM D149

>20

>20

>20

>20

Volume Resistivity (Ω•cm)

ASTM D257

>1014

>1014

>1013

>1010

Burning Test (1200℃,30 min)

Internal

No crack

No crack

No crack

No crack

Flame Resistance

UL 94

V-0

V-0

/

/

UL Yellow Card File Number

/

E499089

///

Recommended Temperature (℃)

SAE J-2236

-60~220

-60~220

-60~220

-60~220

Note: The above data is the average of the overall test, and we can be contacted for more product information.

Application Scenarios

Technical Data

  • TDS
  • MSDS
  • Product Selection
  • Solution
  • Video
  • Certification
  • CS-70 Ceramifiable Solid Silicone Rubber TDS
    Ceramifiable solid silicone: above 600°C (1112°F) it converts to a self-supporting ceramic shell — no burn-through at 1000°C, no cracking at 1200°C/30 min, UL 94 V-0 (Yellow Card E499089).
  • CS-70-G Ceramifiable Solid Silicone Rubber with Glass Fiber Cloth TDS
    Glass-fabric-reinforced CS-70 with the range's highest strength (≥25 MPa tensile, ≥50 N/mm tear) — dimensionally stable after ceramification for structural fire barriers.
  • CS-70-H-G Ceramifiable Solid Silicone Rubber with Glass Fiber Cloth and Ultra-high Temperature Resistant TDS
    Ultra-high-temperature glass-fabric grade — survives 3000°C (5432°F) oxy-acetylene flame for 30 s without burn-through, the highest fire endurance of the range.
  • CS-70-M Ceramifiable Solid Silicone Rubber with Glass Fiber Cloth in the Middle TDS
    Ultra-thin three-layer composite (0.2–0.5 mm) with an embedded glass-fabric core — flexibility plus ceramic strength for space-limited fire sealing and battery covers.
  • CS-70 Ceramifiable Solid Silicone Rubber MSDS
    Safety Data Sheet for CS-70 ceramifiable solid silicone rubber — formulation lists 35–40% ceramic powder with ATH; not classified as hazardous, no health or environmental hazards, non-flammable. For compliance filing, customs clearance, and customer audits.
  • CS-70-G Ceramifiable Solid Silicone Rubber with Glass Fiber Cloth MSDS
    Safety Data Sheet for CS-70-G glass-fabric-reinforced ceramifiable solid silicone rubber — formulation lists ceramic powder and glass-fabric composite; not classified as hazardous, no health or environmental hazards, non-flammable. For compliance filing, customs clearance, and customer audits.
  • CS-70-H-G Ceramifiable Solid Silicone Rubber with Glass Fiber Cloth and Ultra-high Temperature Resistant MSDS
    Safety Data Sheet for CS-70-H-G ultra-high-temperature glass-fiber-reinforced ceramifiable solid silicone rubber — formulation lists ceramic powder and glass-fiber composite; not classified as hazardous, no health or environmental hazards, non-flammable.
  • CS-70-M Ceramifiable Solid Silicone Rubber with Glass Fiber Cloth in the Middle MSDS
    Safety Data Sheet for CS-70-M glass-fiber-cored ceramifiable solid silicone rubber — formulation lists ceramic powder and glass-fiber composite; not classified as hazardous, no health or environmental hazards, non-flammable. For compliance filing, customs clearance, and customer audits.
  • UL Yellow Card (File No. E499089)
    UL Yellow Card File No. E499089 (Category QMFZ2, Plastic Parts) Holder: Guangmai Electronic Technology (Wholly-owned/Affiliate of Taiya) Scope of Covered Products & Grade List: Covers the full line of Taiya silicone foam and solid silicone products, for flame rating verification and factory audit documentation by European and American customers.
